2. Introduction

Downloaded from www.Manualslib.com
Introduction
The BOSE ControlSpace
®
audio signal processor for audio distribution applications such as restaurants, shops, bars, offices, hotels,
conference buildings and sport venues. The main unit includes eight line inputs and eight line outputs.
Four available audio slots allow the addition of up to 8 more audio inputs (2 inputs per card).
For more zones, two AMS-8 system racks can be linked together per system. Multiple choices of user
interfaces are available to give end-users simple and easy-to-use control of their ControlSpace
system.
The BOSE ControlSpace
®
and user interfaces. The software runs on a PC and communicates with the AMS-8 system using serial
communication (RS232).
Features and functions
• Expandable and flexible cardframe architecture
• 8 (up to 16) analogue line level input channels
• Eight analogue line level output channels
• Eight general purpose control inputs and 1 general purpose control output (GPIO)
• Design, configuration and system control via PC-based software programs
• Digital signal processing including: BOSE speaker EQs, delay, gain control and source selection.
• LCD screen and navigation buttons
• Wall Controller functionality (optional IR remote control)
• Local Input Module functionality
• Paging Panel functionality
Quick start
• Connect the audio inputs and audio outputs to the ControlSpace
system racks: connect the 2 racks by using the audio link card, audio link cables and high speed
RS485 rack link).
• Turn on the ControlSpace
After each start up of the ControlSpace
system will play at the default source and default volume level as set in the installation menu.
Abbreviations
CS-WC ControlSpace AMS-8 Wall Controller
™
CS-PP ControlSpace AMS-8 Paging Panel
™
CS-LIM ControlSpace AMS-8 Local Input Module
™
CS-RC ControlSpace ™ AMS-8 Remote Control
CS-TIC ControlSpace ™ AMS-8 Twin Input Card
CS-TOC ControlSpace AMS-8 Twin Output Card
™
CS-EC ControlSpace AMS-8 Ethernet Card
™
CS-MSC ControlSpace AMS-8 Message Storage Card
™
manuals search engine
AMS-8 Audio Management System is a flexible, expandable and high quality
™
AMS-8 Installer software is used to design systems and configure the AMS-8
™
™ AMS-8 system. Because of the default settings the system is now in operation.
™ system, the default settings will be recalled. This means that the
2. Introduction
™ AMS-8
AMS-8 system. (In the case of 2
™
