The paint pattern is tailing.
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
The pressure control dial (9) is set too
low.
Mesh filter handle (26), the spray tip (5),
or the suction hose mesh filter (13) is
clogged.
The suction hose (11) is loose at the
suction hose inlet port (15).
The spray tip (5) is worn.
The paint is too thick.
Increase the pressure control dial (9) to a higher
setting.
Clean mesh filter handle (26), the spray tip (5),
and the suction hose mesh filter (13).
Re-adjust the suction hose (11) to the suction
hose inlet port (15) and use a flat head screw-
driver to tighten the screw on the metal hose
clamp suction hose inlet port (16).
Replace the spray tip (5).
Thin the paint according to the
manufacturer's instructions.
