5.1.3. Electrical connection on the inside :
Standard electrical connection without thermo-electrical drive :
Option : Electrical connection of thermo-electrical drive :
2-PIPE CONNECTION
ELECTRIC MOTOR
GND
INPUT
24V
VALVE
CLIMA CANAL H19 | MANUAL | 9 MAART 2020, 15:23
1
2
3
THERMO-
On the side of the hydraulic connection,
you can find the box for the electrical
connection too.
+ -
+ -
24VDC
0...10V
4-PIPE CONNECTION
GND
INPUT
24V [cooling]
VALVES
24V [heating]
THERMO-
ELECTRIC MOTORS
