I/O Panel
No. Description
1
2
3
4
5
6
7
8
9
CAUTION:
For operating system installation, be sure to plug your USB flash drive into the USB 2.0
Ports (USB12).
Downloaded from www.Manualslib.com
1
17 16 15
USB 2.0 Ports (USB12)
LAN RJ-45 Port
(Intel® I211AT)*
LAN RJ-45 Port
(Intel® I218V)*
Central / Bass (Orange)
Rear Speaker (Black)
Line In (Light Blue)
Front Speaker (Lime)**
Microphone (Pink)
Optical SPDIF Out Port
manuals search engine
2 3
13 11 10
14 12
No. Description
10 USB 3.0 Ports (USB3_34)
11 USB 2.0 Port (USB7)
12 USB 3.0 Port (USB3_5)
13 USB 3.1 Type-A Port (USB31_TA_1)
(ASMedia ASM1142)
14 USB 3.1 Type-C Port (USB31_TC_1)
(ASMedia ASM1142)
15 Clear CMOS Switch
16 Antenna Ports
17 PS/2 Mouse/Keyboard Port
