PCIe Slot Configurations (For CPU with 28 PCIe lanes)
3-Way CrossFireX
Downloaded from
www.Manualslib.com
Single Graphics Card
Two Graphics Cards in
TM
TM
CrossFireX
or SLI
Mode
Three Graphics Cards in
TM
Mode
TM
or 3-Way SLI
Mode
For a better thermal environment, please connect a chassis fan to the motherboard's chas-
sis fan connector (CHA_FAN1, CHA_FAN2 or CHA_FAN3) when using multiple graphics
cards.
manuals search engine
PCIE1
PCIE2
PCIE3
N/A
x16
N/A
N/A
x16
N/A
N/A
x8
N/A
X99 Taichi
PCIE4
PCIE5
N/A
N/A
N/A
x8
x8
x8
21
