CPU Fan Connectors
(4-pin CPU_FAN1)
(see p.1, No. 4)
CPU Optional/Water
Pump Fan Connector
(4-pin CPU_OPT/W_
PUMP)
(see p.1, No. 7)
ATX Power Connector
(24-pin ATXPWR1)
(see p.1, No. 8)
ATX 12V Power
Connector
(8-pin ATX12V1)
(see p.1, No. 3)
Serial Port Header
(9-pin COM1)
(see p.1, No. 21)
manuals search engine
FAN_SPEED_CONTROL
This motherboard
CPU_FAN_SPEED
FAN_VOLTAGE
provides a 4-Pin CPU fan
GND
(Quiet Fan) connector. If
you plan to connect a 3-Pin
1 2 3 4
CPU fan, please connect it
to Pin 1-3.
This motherboard
FAN_SPEED_CONTROL
CPU_FAN_SPEED
provides a 4-Pin water
FAN_VOLTAGE
GND
cooling CPU fan
connector. If you plan to
1 2 3 4
connect a 3-Pin CPU water
cooler fan, please connect
it to Pin 1-3.
This motherboard
12 24
provides a 24-pin ATX
power connector. To use a
20-pin ATX power supply,
please plug it along Pin 1
1 13
and Pin 13.
This motherboard
8 5
provides an 8-pin ATX
12V power connector. To
4 1
use a 4-pin ATX power
supply, please plug it along
Pin 1 and Pin 5.
This COM1 header
RRXD1
DDTR#1
supports a serial port
DDSR#1
CCTS#1
module.
1
RRI#1
RRTS#1
GND
TTXD1
DDCD#1
