Installation and Assembly
induSENSOR MSC 7210
Downloaded from
www.Manualslib.com
4.4
Power Supply, Sensor and Signal Output
The power supply/output cable PC710-6/4 (available as an option) has a bend radius of 24 mm (minimum).
All the connections for power supply / sensors / signal output are located on the controller, see
Fig.
10.
Cable characteristics
Outer diameter cable:
3.0 ... 5.0 mm (AWG 8 ... 4)
Wire:
0.08 ... 0.25 mm² (AWG 28 ... 24)
Wiring
Open the housing in order to connect the sensors and wire the output and supply cable.
Undo the screws.
Pass the sensor and signal cables through the cable glands, see
Unisolate the leads, press wire-end sleeves on the leads and the screening. Use proper crimpers.
The integral cable for LDR-x-CA sensors is ready to use.
Assemble the unit and tighten the screws.
manuals search engine
Fig.
Fig.
8.
9, see
Page 43
