Anhang | EtherNet/IP-Dokumentation
A 4.1.2.3 Object 0x80 Signal Processing
Class Attributes
Attribute ID Name
0 Average 1 type
1 Average 1 number of values for moving average
2 Average 1 number of values for median
3 Average 1 number of values for recursive
10 Average 2 type
11 Average 2 number of values for moving average
12 Average 2 number of values for median
13 Average 2 number of values for recursive
203 Mastering set/reset
204 Mastering value
Average 1/2 Average 1/2 number of
type: values for moving average:
0 - None 2 - 2
1 - Median 4 - 4
2 - Moving 8 - 8
3 - Recursive 16 - 16
...
4096 - 4096
Ablauf:
- Wählen Sie die Mittelungsart (Average 1 or 2 type)
- Legen Sie die Anzahl über die zu mittelnden Werte fest (Average 1 or 2 number of values for ...)
optoNCDT 1900 / EtherNet/IP
Zugriff
Get/Set
Get/Set
Get/Set
Get/Set
Get/Set
Get/Set
Get/Set
Get/Set
Get/Set
Get/Set
Average 1/2 number of
values for median:
3 - 3
5 - 5
7 - 7
9 - 9
Beschreibung
Average 1/2 number of
values for recursive:
2 - 2
3 - 3
4 - 4
5 - 5
...
32000 - 32000
Datentyp
USINT
UDINT
UDINT
UDINT
USINT
UDINT
UDINT
UDINT
BOOL
REAL
Mastering
Set/Reset
0 - Reset
1 - Set
Seite 97
