Operation
induSENSOR MSC 7210
Downloaded from www.Manualslib.com
5.2.3

Zero Point

Connect the sensor to the controller prior to calibration or measurement.
The electrical zero point can be shifted about ±70 % of the measuring range. Examples are shown for zero
point adjustment, see Chap. 5.3.
5.2.4

Signal Gain

The signal gain can be changed about -20 % up to +270 % of the measuring range. Examples are shown for
gain adjustment, see Chap. 5.3.
If the plunger is moved into the sensor, this results in an increase of the output signal, if the plunger is pulled
out further, this results in a decrease of the output signal.
Move the plunger by a defined range, in the ideal case by the complete linear measuring range and
adjust with R3 trim-pot the desired output voltage/current.
It makes no difference whether the plunger is pushed in or pulled out, except that this leads to a increase
respectively decrease of the output signal.
