6.3 Materials

Cutting system
Tank casing
Pump casing
Impeller
Seals
Motor shaft
Performance curve
Dimensions
> FLOWCB is a pumping station designed for private domestic use and for direct
connection to one toilet.
> Installed above ground, directly behind toilet or behind partition wall.
> For light domestic use and with the requirement that an additional toilet must be
installed separately above the flood level.
> O perates in combination with a cistern of minimum 6 litres flushing volume. Proper
operation is not guaranteed at lesser volumes e. g. when using the light flush in a
dual-flush cistern.
> In accordance with DIN EN 12050-3, only a hand basin, a bidet, and a shower tray
can be connected in addition to the toilet. Connection of a washing
machine, dishwasher or bath is not allowed.
> The tank must be in the same room as the utilities to which it is connected.
> In accordance with DIN 1986 Part 3, only domestic sewage and wastewater, with
and without faeces, and without harmful substances (including cat litter, litter tray
liners or wet wipes) are allowed to enter the unit. .
> Use only cleaning products with a pH of 4 – 10 when cleaning utilities
connected to the tank.
> N ot suitable for corrosive, flammable, gaseous or explosive fluids, condensation
from ventilation systems, heat pumps and condensing boilers, and brine from water
softening systems.
> For liquids with a temperature of max. 40 °C, or 60 °C for up to 5 minutes.
> The noise emission value is less than 70dB (A).
Special stainless steel
Polypropylene
Polypropylene
Polyamide
NBR/EPDM
Stainless steel 1.4028 (AISI 420)
See page 43, fig. 12
See page 39

7. Application

33
Materials | Application
