Technical data | Connections | Level control

Technical data

KBN
Free passage
Power cable
Cable length
Weight
Voltage/frequency
Type of current
Nominal current
Motor power P1
Speed
Motor protection
Plug
Protection class
Motor insulation class
Temperature-limiter
Fluid temperature

6.1 Connections

Side discharge line
(with integrated checkvalve)
Side inlets
Toilet connection
(optional connections)
Vent line

6.2 Level control

Switch-on level
Switch-off level
Alarm
6. Technical data
FLOWCB
Shredding system
3G 1.0
1.8 m
7.0 kg
1 x 230 V/50 Hz
Single phase
4.6 A
1.1 kW
2900 r/min
Temperature limiter built into the winding
Schuko plug
IP 44
B
120 °C
Max. 40 °C, 60 °C for 5 minutes
To the right or left. OD = 32 mm/25 mm
1 x DN 50 (right)
1 x DN 50 (left)
1 x DN 100 (front)
1 x DN 100 (side)
Connection of separate vent line DN 50
in odour filter opening (see page 36, fig. 5)
120 mm
45 mm
140 mm
32
