PeakTech DVB-S2 Bedienungsanleitung Seite 55

9. Signal Information:
As part of the signal search (TP search, satellite scan or blind scan), you can see the
bar graph of signal level and signal quality, at the same time the LOCK lamp lights up
with an acoustic signal, which pulsates faster, the higher the signal strength is.
DiSEqC indicates which port is connected to the DiSEqC 1.0 switch. Press the F1
key, the information shown enlarged:
Press the F1 button again, also a full screen display of signal level and carrier/noise ratio is
displayed values.
(Magnified illustration with C/N Ratio and BER information)
-52-
