2. Description of the appliance

2.1. Introduction

This powerful DVB-S2 meter for signal search in satellite systems provides a wide range of
functions for daily use during the installation or testing of satellite systems.
With the graphical user interface with menu control allows all necessary functions such as
the satellite search with corresponding LNB settings, angle calculation of the satellite
system, program search, and the live TV display and media player function simply activate
and use.
The integrated interfaces allow direct connection to the TV via HDMI and thus, this device
is also as a complete replacement for a defective receiver which allows to identify the
errors and fix them quickly.
The AV / IN and AV / OUT input, which can be used to connect external monitors and
output devices for checking external video sources or to display the screen contents,
completes the wide range of functions of this unit, just like the screenshot and video
recording capability of the TV to a connected USB storage.
To be suited for daily use in the installation operation, this meter has a robust plastic
housing, which is also supplied by a practical bag with shoulder strap, in the place and the
extensive measurement accessories square next to the device.
The voltage is supplied via the integrated lithium-ion battery, the included AC adapter or
comfortably in the car by 12V car cigarette lighter adapter.
Through these many important features of this device is the ideal companion every
electrician or television technician in the field.
