FORK

To maintenance refer at an authorized
service centre Betamotor.
To check the tightening torques see as
shown in the figure.
WARNING:
Tightening of the screws should be
carried out by adjusting the torque
wrench to the stability torque with
repeated tightening until stability
torque has been achieved.
REAR SUSPENSION
LEVERAGE
In order to guarantee optimal operation
and duration over time of the progressive
leverage of the rear suspension, it is rec-
ommended to periodically check correct
tightness of nuts and bolts.
Verify that suspension nuts and bolts are at
the indicated torque.
65Nm
65Nm
49
4
20Nm
65Nm
65Nm
EN
