WARNING LIGHTS

1 Headlight indicator
The system activates the indi-
cator in synchrony with the ac-
tivation of the mains beams.
2 Turn indicator lights
The system activates the indi-
cator in synchrony with the ac-
tivation of the turn indicators.
3 Neutral indicator light
The system activates the indicator in synchrony with the engaging of the neutral.
4 MIL indicator light (Engine management system fault)
Indicates a fault in the engine management system. Contact as soon as possible an
authorized Betamotor.
When the key is set to
- the backlighting of the instrument is activated;
- all the lights turn on for about 3" to perform the initial check.
1
2
:

BATTERY REPLACEMENT

Follow this procedure for proper installa-
tion.
The meter includes an internal battery
(CR2032). This battery shall be replaced
only when power runs out.
For replacement remove the headlight
mask. Remove the battery cover located
behind the instrument and pull out the
battery.
In order to install the battery properly, push
the battery as shown on figure to make
1
sure the battery is placed underneath the
metal tab (1).
23
WARNING:
Not following this procedure could
result in permanent damage to the
meter.
2
3
2
4
