BLEEDING THE FRONT BRAKE

To bleed air from the front brake circuit,
proceed as follows:
•Remove the rubber cap 1 from the valve
2.
•Open the sump cap.
•Insert one end of a transparent tube into
a container.
•Pump with the brake lever 2/3 times and
keep the lever pressed.
•Unscrew the valve and let the oil drain.
•If are still visible in the tube repeat above
operation until obtaining a continuous
outflow of oil within no air bubbles.
•Close the valve and release the lever.
NOTE:
During this procedure, continuously top up
the brake pump thank to replace the oil that
is out flowing.
•Remove the tube.
•Replace the rubber cap.
Close the oil reservoir cap.

FRONT BRAKE LINING CONTROL

In order to verify the wear condition of front
brake is enough to view the caliper from
the bottom, where is possible to glimpse
the brake lining tails which will have to
show a brake of 2 mm in thickness. If the
stratum is lesser let's start replacing them.
NOTE:
Perform the check according to the times
shown in the table on page 59.
To replace, contact authorised Betamotor
customer service.
