12. Technical data

Drive system
Motor brushless bottom
bracket motor
Performance 250 W nominal
Speed (max)
25 km/h or 15½ mph
Motor settings
3
Torque (max) 50 Nm
Battery
Type Lithium-Ion
Capacity 302 Wh nominal
Voltage
48 V
Charging cycles 3 h normal
Ladezyklen 500
Distance (max) 105 km (depending on
rider, riding style, to-
pography and motor
setting)
Weight (total system): 5,9 kg
Permissible total weight (max): 120 kg (vehicle +
rider + freight)
40
Dimensions (width x height x depth)
Battery 80 x 276 x 80 mm
Drive system
205 x 205 x 39 mm
Tightening torque values for screw connections
Battery holder on the fra- 4,5 Nm
me (with safety screws)
Electronic bottom bracket 15 Nm
right-hand assembly side
(greased)
bottom bracket mounting 60 Nm
(greased)
Crank screw left / right 32 Nm
(with safety screws and
grease on square shaft)
Pedal left / right 35 Nm
Connector cover to 1,4 Nm
battery holder
Chain wheel screws, 9 Nm
steel
Imprint
Responsible for content and illustrations
Veidt Anleitungen
Mittelstr. 4
D-65307 Bad Schwalbach
Tel +49 6124 6054161
Veidt-Anleitungen@email.de
legally checked by professional lawyers for trade
protection
± 0,5 Nm
These operating instructions are covered by require-
ments and scope of EN ISO (European Norm, Interna-
± 2 Nm
tional Standards Organization) 4210:2014 and 15194.
When supply and effective use are outside the range
of these instructions, the relevant instructions by the
± 3 Nm
manufacturer of the bicycle used must be included.
± 2 Nm
© reproduction, copying and translation
including any other active commercial use (also in
the form of excepts and / or in printed or electronic
Form) are only permissible after previous agreement
± 2 Nm
to same in written form.
± 0,5 Nm
Pendix DE Edition 8.13, October 2015
± 2 Nm
