• 6 x SATA3 6.0 Gb/s connectors by Intel® Z87, support RAID
Storage
(RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage
Technology 12 and Intel Smart Response Technology), NCQ,
AHCI and Hot Plug
• 4 x SATA3 6.0 Gb/s connectors by ASMedia ASM1061, sup-
port NCQ, AHCI and Hot Plug
• 1 x COM port header
Connector
• 1 x Power LED header
• 2 x CPU Fan connectors (1 x 4-pin, 1 x 3-pin)
• 4 x Chassis Fan connectors (1 x 4-pin, 3 x 3-pin)
• 1 x Power Fan connector (3-pin)
• 1 x MOS Fan connector (3-pin)
• 1 x 24 pin ATX power connector
• 2 x 8 pin 12V power connectors (Hi-Density Power Connec-
tor)
• 1 x SLI/XFire power connector
• 1 x Front panel audio connector
• 2 x USB 2.0 headers (support 6 USB 2.0 ports)
• 1 x Vertical Type A USB 3.0
• 2 x USB 3.0 headers (support 4 USB 3.0 ports) (ASMedia
Hub)
• 1 x Power Switch with LED
• 1 x Reset Switch with LED
• 1 x Clear CMOS Switch
• V-Probe
laid
• Rapid OC Button: +/- buttons to adjust OC frequency
• 1 x PCIe ON/OFF Switch
• 1 x Post Status Checker (PSC)
• 1 x Slow Mode Switch
• 1 x LN2 Mode Switch
• 1 x BIOS Selection Switch
• 2 x 64Mb AMI UEFI Legal BIOS with Multilingual GUI sup-
BIOS
Feature port (1 x Main BIOS and 1 x Backup BIOS)
• Supports Secure Backup UEFI Technology
• ACPI 1.1 Compliance Wake Up Events
• SMBIOS 2.3.1 Support
• CPU, DRAM, PCH 1.05V, PCH 1.5V Voltage Multi-adjust-
ment
TM
: 2 x 7-set of onboard voltage measurement points
