Overview
2
1
3
4
5
6
7
8
9
10
11
Operator panel
1
Speed control (drive and reverse)
2
Emergency Stop button
3
Steering and horn
4
Power supply cordfor the internal battery charger
5
Suction hose
6
Running board with safety switch
7
Mounting pedal for squeegee
8
Squeegee
9
Squeegee lock
10
Squeegee holder
11
Manual unlocking of the brake (the button must be held down!)
12
Chargng plug for the external battery charging unit (only for non BMS
13
machines)
Operator panel
33
32 31
30
Spot
34
35
36
37
Keyswitch
27
Display (on switch-on: Total hours / Error message: see Faults)
28
Brush ON/OFF button ( +/- button for the brush pressure)
29
Vacuum button
30
Cleaning solution ON/OFF button ( +/- button for the dosing quantity)
31
Point cleaning, short-term maximum power consumption
32
Battery fully charged
33
Battery charging, only with the internal battery charger (mains plug plugged
34
in)
Battery/mains unit malfunction
35
Service indicator
36
Slow speed button (used for difficult driving situations)
37
Start/Stop button (loads last used settings)
38
Eco-Function (energy-saving mode)
39
Recovery tank full indicator
40
Battery indicator
41
12
29
28
27
Start
Start
Stop
Eco
38
39
40
41
26
25
24
13
14
15
Brush unit
14
Adjustment lever for tools
15
Full recovery tank probe
16
Recovery tank
17
Drainage hose
18
Flex tank with dosing cup
19
Half-full level (red line)
20
Max. filling level (red line)
21
Solution supply pipe and filter
22
Dirt sieve
23
Vacuum air filter
24
Maintenance cap
25
Seal for the tank lid
26
Preparation for operation/Operation
Batteries
Safety measures when working with batteries:
• Protective goggles must be worn when working on the
batteries.
• Do not subject batteries to an open flame or heat as there is a
danger of explosion from the electolytic gas present in the
cells!
• No smoking!
• Danger of chemical burns!
Caution:
The battery must always be clean and dry. Do not place any
metallic objects on the battery.
The integrated charging unit is only suitable for maintenance-free
gel traction block batteries.
23
22
21
20
19
16
17
18
