• Dual Channel DDR3 memory technology
Memory
• 4 x DDR3 DIMM slots
• Supports DDR3 3000+(OC)/2933(OC)/2800(OC)/2400(OC)
/2133(OC)/1866(OC)/1600/1333/1066 non-ECC, un-buffered
memory
• Max. capacity of system memory: 32GB
• Supports Intel® Extreme Memory Profile (XMP) 1.3 / 1.2
• Distortion-Free Slot
• 2 x PCI Express 3.0 x16 slots (PCIE1/PCIE3: single at x16
Expansion
Slot
(PCIE1); dual at x8 (PCIE1) / x8 (PCIE3))
• 1 x PCI Express 2.0 x4 slot
• 1 x PCI Express 2.0 x1 slot
• 1 x half mini-PCI Express slot
• 1 x mSATA/mini-PCI Express slot
* mSATA/mini-PCI Express slot is shared with the SATA3_4
port.
• Supports AMD Quad CrossFireX
• Supports NVIDIA® Quad SLI
• Intel® HD Graphics Built-in Visuals and the VGA outputs can
Graphics
be supported only with processors which are GPU integrated.
• Supports Intel® HD Graphics Built-in Visuals : Intel® Quick
Sync Video with AVC, MVC (S3D) and MPEG-2 Full
HW Encode1, Intel® InTruTM 3D, Intel® Clear Video HD
Technology, Intel® InsiderTM, Intel® HD Graphics 4400/4600
• Pixel Shader 5.0, DirectX 11.1
• Max. shared memory 1792MB
• Dual VGA Output: support HDMI and DisplayPort ports by
independent display controllers
• Supports HDMI Technology with max. resolution up to 4K x
2K (4096x2304) @ 24Hz
• Supports DisplayPort with max. resolution up to 4K x 2K
(4096x2304) @ 24Hz
• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI (Compliant HDMI
monitor is required)
• Supports HDCP function with HDMI and DisplayPort ports
• Supports Full HD 1080p Blu-ray (BD) playback with HDMI
and DisplayPort ports
TM TM
and CrossFireX
TM TM
and SLI
Z87M OC Formula
7
