3.2 Dimensions

The indicated dimensions are the same for all control variants of the DDE range.
The following drawing shows the DDE-PR control variant.
17.5 110
105
120
Fig. 3 Dimensional sketch
Pump type
DDE 6-10
DDE 15-4
12
D
4 x Ø6
A1 [mm] B [mm]
251 196
251 200.5
A1
G 5/8
161
C [mm]
46.5
39.5
17
D [mm]
24
24
