Power LED and Speaker
Header
(7-pin SPK_PLED1)
(see p.1, No. 19)
Serial ATA3 Connectors
(SATA3_0_1:
see p.1, No. 14)
(SATA3_2_3:
see p.1, No. 15)
(SATA3_4_5:
see p.1, No. 16)
(SATA3_6_7:
see p.1, No. 17)
(SATA3_A1_A2:
see p.1, No. 18)
USB 2.0 Headers
(9-pin USB1_2)
(see p.1, No. 24)
(9-pin USB3_4)
(see p.1, No. 23)
USB 3.0 Headers
(19-pin USB3_5_6)
(see p.1, No. 13)
24
SPEAKER
DUMMY
DUMMY
+5V
1
PLED+
PLED+
PLED-
USB_PWR
P-
P+
GND
DUMMY
1
GND
P+
P-
USB_PWR
1
Dummy
IntA_PA_D+
IntA_PB_D+ IntA_PA_D-
IntA_PB_D- GND
GND IntA_PA_SSTX+
IntA_PB_SSTX+
IntA_PA_SSTX-
GND
IntA_PB_SSTX-
GND IntA_PA_SSRX+
IntA_PB_SSRX+ IntA_PA_SSRX-
IntA_PB_SSRX- bus
V Vbus
Please connect the
chassis power LED and
the chassis speaker to this
header.
These ten SATA3
connectors support SATA
data cables for internal
storage devices with up to
6.0 Gb/s data transfer rate.
* To minimize the boot
time, use Intel® X299
SATA ports (SATA3_0~7)
for your bootable devices.
* If M2_1 is occupied by
a SATA-type M.2 device,
SATA3_1 will be disabled.
* If M2_2 is occupied by
a SATA-type M.2 device,
SATA3_0 will be disabled.
* If M2_3 is occupied by
a SATA-type M.2 device,
SATA3_7 will be disabled.
There are two headers
on this motherboard.
Each USB 2.0 header can
support two ports.
There are two headers
on this motherboard.
Each USB 3.0 header can
support two ports.
