• 2 x Ultra M.2 Sockets (M2_1 and M2_3), support M Key
type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and
M.2 PCI Express module up to Gen3 x4 (32 Gb/s)**
** Supports Intel® Optane
** Supports PCIe RAID (on M2_2 and M2_3)
** Supports NVMe SSD as boot disks
** Supports ASRock U.2 Kit
• 1 x Virtual RAID On CPU Header
Connector
• 1 x TPM Header
• 1 x Power LED and Speaker Header
• 2 x RGB LED Headers
* Support up to 12V/3A, 36W LED Strip
• 1 x CPU Fan Connector (4-pin)
* The CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
• 1 x CPU Optional/Water Pump Fan Connector (4-pin)
(Smart Fan Speed Control)
* The CPU Optional/Water Pump Fan supports the water cooler
fan of maximum 1.5A (18W) fan power.
• 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Con-
trol)
• 1 x Chassis Optional/Water Pump Fan Connector (4-pin)
(Smart Fan Speed Control)
* The Chassis Optional/Water Pump Fan supports the water
cooler fan of maximum 1.5A (18W) fan power.
* CPU_OPT/W_PUMP, CHA_FAN1, CHA_FAN2 and CHA_
FAN3/W_PUMP can auto detect if 3-pin or 4-pin fan is in use.
• 1 x 24 pin ATX Power Connector (Hi-Density Power Con-
nector)
• 1 x 8 pin 12V Power Connector (Hi-Density Power Connec-
tor)
• 1 x Front Panel Audio Connector (15μ Gold Audio Connec-
tor)
• 1 x Thunderbolt AIC Connector (5-pin)
• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports
ESD Protection (ASRock Full Spike Protection))
• 2 x USB 3.0 Headers (Support 4 USB 3.0 ports) (ASMedia
ASM1074 Hub) (Supports ESD Protection (ASRock Full
Spike Protection))
• 1 x Front Panel Type C USB 3.1 Header (ASMedia ASM3142)
* Supports USB PD 2.0 up to 12V@3A (36W) charging
• 1 x Dr. Debug with LED
TM
Technology (on M2_2 and M2_3)
