Connect the third point, taking care that the
power take-off axis is parallel to the ground,
ensure that the third point works when the
machine is in a horizontal position and resting on
the ground, in the center of the slot, in order to
avoid any irregularities in the ground, pulllling or
jamming of the third point itself (see Fig. 08).
- Connect the hydraulic hoses to the tractor distributor,
making sure they are connected correctly.
- Operate the lever of the valve slowly to check the
opening and closing of the collector.
Maximum permissible operating pressure: 150 bar.
- Attaching the machine to the tractor is considered a
hazardous operation: carefully follow the instructions given
and keep a safe distance from the maneuvering area.
- Place the tractor and the machine on compact and flat
ground.
In the machines applied to the rear connection of the tractor, due to the weight of the machine, the tractor-operating machine as a
whole may be unstable, causing difficulty in driving and taking corners, so it is advisable to check whether or not the front part of the
tractor, to be carried out in any event, is within the limits and in the manner indicated by the manufacturer.
.
.
Code. 29050071
Release 01/08/2017
M x (s1 + s2 ≤
) 0.2 X T X i + Z x (d+ i)
M ≤ 0.3 T
36
i = wheelbase tractor;
where:
d = distance of the front axle of the ballast;
= distance of the lower lifting arms wheels
s
1
from the rear axle of the tractor;
=distance of the lower linkages from the
s
2
center of gravity of the machine (650
mm);
T=weight of tractor with operator;
Z =weight of the ballast;
M =weight of the grass cutter (see par.
"Technical Data");
As far as lateral stability is concerned, since a
