56 AVENTICS | HF03/HF02 | 1987765472–BDL–001–AB
Installation
.
View A
Fig. 6: HF03 pneumatic connections
View A
Fig. 7: HF02 pneumatic connections
Only use plug accessories made of plastic (polyamide) from
our pneumatic catalogue for working connections 2 and 4.
Please ensure that enough free space is left for the
pneumatic hoses so that the permitted minimum bending
radii are adhered to.
X
1
A
5
1
X
View B
3
5
5
2
4
X
1
View B
5
3
2
4
1 X
R
B
R
