Assembly

6.1 Assembling the valve system with bus coupler

You will receive your individually configured valve system completely fitted with all
components:
Valve terminal
Bus coupler
Up to six I/O modules (if needed)
Up to three module extensions (if needed)
The operating instructions accompanying the VS describe in full how to assemble
the entire valve system. Any mounting orientation may be used with the VS. The
dimensions of the complete VS vary according to module equipment.

6.2 Labeling the module

Inscribe the address provided/used for the bus coupler on the bus coupler in the
BTN field.
Label the connections directly on the labels of the input/output modules.
The markings on the connections indicate which labels are assigned to the
connections.
Fig. 5: Labels on the bus coupler (CMS-B-BEIP), input module (8DI_M8), and output
module (8DO_M8) (examples)
