Description of the TV 551/701 Navigator

The TV 551/701 Navigator pumping system con-sists of a pump with
a dedicated controller fixed to it. The system is available in five
models for TV 551 and three models for TV 701. The models of each
group differ in the high vacuum flange.
The TV 551 Navigator five models are:
The TV 701 Navigator three models are:
The following figures show the eight models. The pumps only are
available with the following models:
1
2
TV 551/701 Navigator User Manual / 87-900-934-01
Model 969-8832 with ISO 160 high vacuum flange;
Model 969-8842 with ISO 160 F high vacuum flange;
Model 969-8833 with ConFlat 8" external diameter high vacuum
flange;
Model 969-8835 with ConFlat 6" external diameter high vacuum
flange.
Model 969-8836 with ISO 200 high vacuum flange;
Model 969-8843 with ISO 200 F high vacuum flange;
Model 969-8837 with ConFlat 10" external diameter high vacuum
flange.
TV 551 Navigator pumps:
Model 969-8922 with ISO 160 high vacuum flange
Model 969-8944 with ISO 160 F high vacuum flange
Model 969-8923 with ConFlat 8" external diameter high vacuum
flange
Model 969-8925 with ConFlat 6" external diameter high vacuum
flange
TV 701 Navigator pumps:
Model 969-8926 with ISO 200 high vacuum flange
Model 969-8945 with ISO 200 F high vacuum flange
Technical Information

Description of the TV 551/701 Navigator
