TV 551/701 Navigator User Manual / 87-900-934-01
How to Connect the Open-Collector Inputs of the Controller
W L
R/W L
R/W L
R/W N
R/W N
R/W L
Reserved to Agilent service
R/W L
R/W N
Reserved to Agilent service
R N
R N
R N
R N
R N
Technical Information
Pump life/ cycle time/ cycle
number reset
Interlock type (default = 1)
Analog output type: output
voltage signal proportional to
frequency or power
Rotational frequency setting
(Hz)
Maximum rotational
frequency in Hz (active only
in Stop condition)
Set vent valve on/off
(on = closed)
Set the vent valve operation
Vent valve opening delay
(expressed in 0.2 sec)
Pump current in mA dc
Pump voltage in Vdc
Pump power in W (pump
current x pump voltage duty
cycle)
Driving frequency in Hz
Pump temperature in °C
(M)
17
To reset write
'1'
Impulse = 0
Continuous = 1
0 = frequency
1 = power
(default = 0)
272 to 714
(default = 714)
272 to 714
(default = 714)
On = 1
Off = 0
(default = 1)
Automatic = 0
(see note 1.)
On command =
1 (see note 2.)
0 to 65535
(corresponding
to 0 to 13107
sec)
0 to 70
265/300
