Table of Contents
Installation Manual
0
Safety Precautions...........................
Accessories........................................ 6
1
Installation Summary - Indoor Unit........
2
3
Unit Parts.......................................... 10
5
Outdoor Unit Installation... 20
1. Select installation location.................. 20
2. Install drain joint................................ 21
3. Anchor outdoor unit.......................... 22
4. Connect signal and power cables.......23
4
8
4 Indoor Unit Installation........ 11
1. Select installation location.......................... 11
2. Attach mounting plate to wall.................... 12
3. Drill wall hole for connective piping............ 12
4. Prepare refrigerant piping........................... 14
5. Connect drain hose.................................... 15
6. Connect signal cable.................................. 17
7. Wrap piping and cables.............................. 18
8. Mount indoor unit..................................... 18
