Wall
Indoor
Fig.3.2
Fig. 3.2
MOUNTING PLATE DIMENSIONS
Different models have different mounting plates.
In order to ensure that you have ample room to
mount the indoor unit, the diagrams to the right
show different types of mounting plates along
with the following dimensions:
Width of mounting plate
•
Height of mounting plate
•
Width of indoor unit relative to plate
•
Height of indoor unit relative to plate
•
Recommended position of wall hole (both
•
to the left and right of mounting plate)
Relative distances between screw holes
•
Correct orientation of Mounting Plate
Outdoor
101mm (4in)
Left rear wall
hole 65mm (2.5in)
192mm (7.55in)
Left rear wall
hole 65mm (2.5in)
138mm (5.45in)
Left rear wall
hole 65mm (2.5in)
34mm (1.35in)
219mm (8.6in)
53.5mm 76mm(3in)
(2.1in)
Left rear wall
174.3mm (6.85in)
hole 65mm (2.5in)
1080mm (42.5in)
389mm (15.3in)
172mm (6.8in)
52mm (2.05in)
Left rear wall
hole 90mm (3.54in)
1259mm (49.55in)
NOTE: When the gas side connective pipe is
Φ
16mm(5/8in) or more, the wall hole should
be 90mm(3.54in).
348.4mm (13.7in)
179mm (7.05in)
136mm (5.35in)
Indoor unit outline
Right rear wall
722mm (28.45in) hole 65mm (2.5in)
426mm (16.8in)
232mm (9.15in)
128mm (5.05in)
Indoor unit outline
Right rear wall
802mm (31.6in) hole 65mm (2.5in)
517.4mm (20.37in)
144mm (5.65in)
Indoor unit outline
Right rear wall
hole 65mm (2.5in)
965mm (38in)
Model C
553mm (21.77in)
300mm (11.8in)
53.5mm (2.1in)
Indoor unit outline
148.7mm
(5.85in)
47mm (1.85in)
Right rear wall
151mm (5.95in) hole 65mm (2.5in)
Model D
643.6mm (25.3in)
257mm (10.1in)
332mm (13.05in)
Indoor unit outline
52mm (2.05in)
Right rear wall
hole 90mm (3.54in)
Model E
