Set up
1 x AT 70 Groundplane antenna
several Synexis RP8 Tour guide receivers and headphones to listen to foreign languages
Charger for Synexis RP8 (Synexis C8, C10, C20, C30, CHP)
Connection
Connect the DAN In input
18
of the first interpreter station to the DAN connection
output
of the first interpreter station to the DAN In input
17
(10 metres long) to connect the first interpreter station to the SIS control unit. To connect the interpreter stations to one another use
e.g. the CA 3105 cable (5 metres long). Connect the DT 394.SIS headset to the interpreter stations for instance.
For the speaker connect a microphone to the Original In input
pre-amplifier or mixing console with phantom power is needed.
If more listeners are to listen to the discussion without taking part (e.g. press), the Synexis RP8 tourguide receivers with headphones and
the stationary Synexis TS8 transmitters can be used. Connect the input (In) of a stationary Synexis TS8 transmitter to the output
SIS control unit and for each foreign language connect one stationary Synexis TS8 transmitter to the appropriate outputs
control unit. As a standard one original language and a maximum of 3 foreign languages can be connected. If the SIS control unit is
equipped with two other plug-in modules each with 4 connections, one original language and a maximum of 11 foreign languages can be
connected.
Connect the outputs of the Synexis TS8 transmitters to the inputs of the AD 808 combiner. Connect the antenna e.g. AT 70 to the
combiner by using the AVK 800/100 cable.
8
of the SIS control unit. Connect the DAN Out
of the second interpreter station and so on. Use e.g. the CA 3110 cable
18
of the SIS 121 control unit. If you use a condenser microphone, a
11
57
of the
6
of the SIS
6
