Set up
2 x Synexis TS8 Stationary transmitters for 2 foreign languages
1 x AD 808 Combiners 4 to 1 for transmitter level
1 x AVK 800/10 Cable, low-attenuation
1 x AT 70 Groundplane antenna
several Synexis RP8 Tour guide receivers and headphones to listen to foreign languages
Charger for Synexis RP8 (Synexis C8, C10, C20, C30, CHP)
Charger for MCW-D 2071/2073 (MCW-D 10)
Connection
Connect the DAN In input
of the first interpreter station to the DAN connection
18
output
of the first interpreter station to the DAN In input
17
(10 metres long) to connect the first interpreter station to the SIS control unit. To connect the interpreter stations to one another use e.g.
the CA 3105 cable (5 metres long). Connect the DT 394.SIS headset to the interpreter stations.
Connect the input (In) of the CA 2451 PCB (25-pin Sub-D) of the MCW-D 200 control unit to the output
unit and the output (Out) of the MCW-D 200 control unit to the input
There are several headphones available to connect to the MCW-D microphone units, such as DT 1 and DT 2.
If more listeners are to listen to the discussion without taking part (e.g. press), the Synexis RP8 tour guide receivers with headphones and the
stationary Synexis TS8 transmitters can be used. Connect the input (In) of a stationary Synexis TS8 transmitter to the output
control unit and for each foreign language connect one stationary Synexis TS8 transmitter to the appropriate outputs
unit. As a standard one original language and a maximum of 3 foreign languages can be connected. If the SIS control unit is equipped
with two other plug-in modules each with 4 connections, one original language and a maximum of 11 foreign languages can be connected.
Connect the outputs of the Synexis TS8 transmitters to the inputs of the AD 808 combiner. Connect the antenna e.g. AT 70 to the
combiner by using the AVK 800/100 cable.
Connect a loudspeaker to an SIS output by using an external amplifier, if the loudspeaker is to be activated from the interpreter station
(e.g. for giving information to the speaker or technician).
of the SIS control unit. Connect the DAN Out
8
of the second interpreter station and so on. Use e.g. the CA 3110 cable
18
(from MCW-D) of the SIS control unit. Use CA 3125 cables.
9
55
10
(to MCW-D) of the SIS control
of the SIS
6
of the SIS control
6
