SIS 1202 Interpreter Station
Right Side of the Interpreter Station
Card reader
16
Network output (to connect to the next interpreter station)
17
Network input (to connect to the control unit or the previous interpreter station)
18
Microphone input with 12 V phantom powering to connect a microphone
19
Headphone connection 6.35 mm jack (1/4")
20
Headphone connection 3.5 mm jack (1/8"), also for the connection of a recorder
21
Left Side of the Interpreter Station
16
, - same as above
16 19 21
Connection for power supply unit
22
19
20
21
22
18 17
19
20
21
