2. KIT COMPONENTS
2.4 SC-7000-EUR Signal Clamp
(included with AT-7030-EUR, option for
AT-7020-EUR)
The SC-7000-EUR works in circuits up to
JAW
600V with max. 400A AC/DC in Category
I-IV electrical environments.
The clamp accessory is used for applications
when there is no access to the bare

HAND GUARD

conductors. The clamp attachment enables
the AT-7000-TE Transmitter to induce a
signal through the insulation into either
energized or de-energized wires. The
JAW TRIGGER
signal will travel through the wire in both
directions and into all the branches. This
transmission method will not damage any
sensitive electronic equipment connected to
INPUT LEADS WITH
BANANA PLUG
the circuit.
