2. KIT COMPONENTS
Main applications
Help guide
Setting menu
Buzzer volume adjustment
Home menu
Language
Backlight
Setting
Help Guidance
Sensitivity*
Smart Sensor Range SHORT
Breaker Voltage
*Note: The Auto and Manual sensitivity mode can be easily changed by pressing the + and
– key at the same time when the receiver is in a tracing mode. When sensitivity mode is set
to "Auto" manual adjustment is disabled.
ENERGIZED:
DE-ENERGIZED:
Figure 1a: Overview of all elements on home screen
Figure 1b: Overview of all elements on the setting menu
Select desired language
25%, 50%, 75%, 100%
DEFAULT : Restore default settings
ON : Device will guide you through each mode
OFF : Device will start without guidance
MAN : Manual sensitivity adjustment (+) and (-) keys
AUTO : Auto sensitivity adjustment
: For wire detection up to 91.4 cm (36 in)
LONG : For wire detection between 91.4 cm (36 in) and 610 cm (240 in)
120V : For 110V to 120V systems
230V : For 220V to 240V systems
- -
Sensitivity adjustment
7
