VDS-CompactDesign
PROFIBUS DP
Service, maintenance
Definition of terms in accordance with IEC 60079-17:
Maintenance and service: A combination of all tasks carried out to maintain an
object in or return it to a condition which corresponds to the requirements of the
respective specifications and ensures that the required functions can be
performed.
Inspection: Careful examination of the object with the goal of making a reliable
statement on the condition of the object. Inspection is carried out without
disassembly or, if necessary, with partial disassembly, supplemented by
procedures such as taking measurements.
Visual inspection: An inspection which determines visible faults, such as missing
screws, without the use of access equipment or tools.
Close-up inspection: An inspection which, in addition to the faults determined by
visual inspection, also determines faults, such as loose screws, that can only be
found by using access equipment, e.g. steps (if required) and tools. For close
inspections, the housing usually does not need to be opened and the equipment
can usually stay energized.
Detailed inspection: An inspection which, in addition to the aspects determined by
close inspection, determines faults, such as loose connections, that can only be
found by opening housings and/or using tools and testing equipment, if required.
• Maintenance measures may only be performed by personnel with equal or
comparable qualification acc. to TRBS 1203.
• Accessory parts for use in explosive areas must comply with the requirements
stipulated in the European directives and national laws.
• Components may only be exchanged for original spare parts that are also
approved for use in explosive areas.
• Devices in ex areas must be cleaned regularly. The intervals must be stipulated
by the operator in accordance with the local ambient conditions.
• After service and/or maintenance, all barriers and warnings must be returned to
their original locations.
• Disassemble the device as soon as malfunctions occur. Maintenance of internal
components cannot be conducted on site. Send the device to the manufacturer
for inspection.
Activity
Visually inspect the integrity of the Bus
1
module, remove dust deposits
2 Inspect the entire system
Disposal
Dispose of packaging and used parts in accordance with the regulations of the
country where the device has been installed.
Visual inspec-
monthly
AVENTICS | C-Design | 8858903033-BAL-001-AE
Close-up
tion, inspection,
every 6 months
●
Responsibility of the operator
Detailed
inspection,
every 12 months
39/40
