VDS-CompactDesign
PROFIBUS DP
• To achieve the protection class and function all seals have to be intact and fit in cor-
rect position.
• The protection class can only be achieved if all unused plugs are sealed with covers or
endplugs.
• Switches and configuration must not be changed during operation. Changed settings
only become valid after power recycle.
• No equalizing currents due to potential differences must run via the shield, otherwise
the earthing have to be made via separate wires.
