VDS-CompactDesign
PROFIBUS DP
The bus module is configured via software COM Profibus (Siemens) as a Profibusmodul
12 MB station. The GSD file
RXP_CD12.gsd
are within the delivery or could be ordered separately 546 046 941 2. The file must be cop-
ied into the same directory or user area in which the COM software is installed.
For configuration of the station, the station type Profibusmodul 12MB should be chosen via
the family (valves/ Aventics for RXP_CD12.gsd). After marking of the mask configuration
the values according to the tables have to be set. The inputs must be configure in front of
the outputs. Depending of the number of valve units the input and output bytes have to be
set.
Branch
Number
Switch SW 1
Bit 2
1
on
2
on
3
on
4
on
Table 4 Configuration as Valve Unit with Sensor Inputs
Branch
Number
Switch SW 1
Bit 2
1
off
2
off
3
off
4
off
Table 5 Configuration as Valve Unit without Sensor Inputs
PLC
0. Module
Bit 3
Bit 4
Input
Bytes
on
on
4
on
off
8
off
on
12
off
off
16
PLC
0. Module
Bit 3
Bit 4
Output
Bytes
on
on
4
on
off
8
off
on
12
off
off
16
AVENTICS | C-Design | 8858903033-BAL-001-AE
1. Module
Software
Output
COM ET 200
Bytes
19
4
23
8
27
12
31
16
1. Module
Software
COM ET 200
35
39
43
47
Software COM
ET 200
35
39
43
47
