Recommended hydraulic oil
Shell Risella D15 (ISO VG 10 - ISO VG 68 to DIN
51519)
Grade: without H1 approval:
Order No.: 001 365 614
Grade with H1 approval:
Order No.: 001 365 647
6.2 Daily maintenance of the
guillotine
Clean the guillotine after use and oil the blades (12)
lightly.
6.2.1 Lubrication
After every cleaning, coat the sliding surfaces and
the blades lightly with EFA special grease ( 001 365
621).
6.3 Monthly maintenance
6.3.1 Guide ledge clearance
Check the guide ledge clearance (1, 12, 16) at reg-
ular intervals. In order to avoid breakage, the blades
must always be adjusted without clearance but with
free movement.
6.3.2 Air conditioner
The air conditioner must be inspected at regular in-
tervals, the condensed water drained from the wa-
ter trap and the special oil (001 365 612) topped up.
6.3.3 Hydraulic power pack
Check the oil level at regular intervals and top up, if
necessary. See also Chapter 3.1.3 "Hydraulic power
pack" (p. 17) and the separate operating manual for
the hydraulic power pack.
CAUTION!
Pay attention to cleanliness! Use a filler funnel with
a fine-mesh screen (mesh width approx. 0.4 mm).
At least once a year, drain the oil filling, inspect for
soiling and replace if necessary.
The hydraulic oil is classified as a haz-
ardous substance and must be used
and disposed of accordingly. On no
account may hydraulic oil drain into
the sewage system or escape into the
atmosphere.
Schmid & Wezel
D 75433 Maulbronn
6.3.4 Sharpening the blades
Incorrectly sharpened blades detract from your pro-
ductivity and also constitute considerable risks for
the user.
We have set up a sharpening service
for you in our Service department. In
this case, please contact your nearest
contract workshop or our parent com-
pany directly.
If used correctly, resharpening of the blades (12) is
normally not necessary.
If required, the blades can also be resharpened with
minimum material removal using commercially
available grinders.
Do not use force as parts could be
damaged!
Use only original EFA spare parts!
6.4 Repair by After-Sales Service
Disconnect the machine from the
hydraulic network before starting
any repair work!
Repairs may only be carried out by specialist
personnel.
Our Service department is at your disposal for
all repair work. In the event of a repair, please
contact your nearest contract workshop or our
parent company directly.
On request, spare parts lists can be supplied to
the repair workshop with qualified specialist
staff.
After every repair, the gear units must be
repacked with grease!
7. Transport and storage
The machine must be stored in a dry, well-ventilated
room.
The machine must be cleaned as described in Chap-
ter 6.1.2 "Cleaning the guillotine" (p. 22) and trans-
ported in dry condition.
Ensure that the machine is not damaged during
transport.
Seite/ Page
23/ 33
Ausführung/ Version
04.2012
