40
®
ing catman AP‐data will be overwritten during recovery. You will need a spe­
cially prepared USB memory stick, a keyboard and, where possible, a (digital)
monitor that you can connect directly to the CX22‐W (DVI output) in order to
recover the system. Load the program to implement recovery over the Internet
from HBM, see www.hbm.com/Software
Important
During recovery, Partition C of the internal memory will be deleted and rewrit­
ten. Make sure that the CX22‐W has a power supply during the entire recov­
ery process.
Tip
Restoring the system with the latest software is equivalent to a system
update.
Procedure
1. Connect a (new) USB memory stick with at least 1 GByte capacity to your
PC.
The USB memory stick will be reformatted, i.e. all data on the stick will be
lost. Create a backup of your data beforehand if necessary.
2. Start the program "CX22_Recovery_Setup.exe".
3. After the USB memory stick has been written to, click on Finish in the last
dialog and eject the USB memory stick via Windows.
4. Switch off the CX22‐W and connect the USB memory stick, keyboard and
monitor (if available).
5. Switch on the CX22‐W.
6. Wait for the beep sounds of the CX22‐W during booting and then press
F11 several times (four to five times within 10 seconds is sufficient).
7. If a monitor is connected, the boot menu will appear, otherwise wait for
another 30 seconds.
8. Press the down arrow key once and then the return key. This selects the
boot medium (boot device) on the USB connection.
If the USB memory stick has an LED, this will show that data transmission
is taking place. A special program is started to implement the recovery
procedure.
9. If a monitor is connected, click in the next dialog on Recovery. Otherwise,
wait approx. 3 minutes and then press the return key.
HBM
QuantumX Data Recorder CX22‐W
