2) When raising the sewing machine, push feed base
hold periphery ribs
At this time, do not hold feed base
DANGER :
1. Do not hold any part other than periphery ribs
2. Confirm that hinge stopper
CAUTION :
If you raise the sewing machine from its home position with the feed base remained near side, the feed
base can move to pinch hands and fingers leading to an unexpected injury.
4
中国缝纫机设备网
When raising
sewing machine
located on the front side of the sewing machine bed to slowly lift it.
and feed guide shaft fixing base
is locked with support shaft
A
away from you (in the direction of the arrow), then
.
of machine head.
.
3) When returning the sewing machine, support
periphery ribs of the machine bed with your left
hand, hold grip of the hinge stopper section
with your right hand, pull it to this side (direction A)
to release the lock and slowly lower the sewing
machine after confirming that there is no tool
such as screwdriver and the like in the bottom
cover.
4) Take your right hand off from the hinge stopper
section, support periphery ribs
bed with your both hands, and further lower the
sewing machine.
DANGER :
1. Do not lower the sewing machine while
keeping pulling the hinge stopper in
direction A, in order to prevent pining
of fingers, hands and arms under the
sewing machine leading to a serious
injury.
2. Do not hold feed base
shaft fixing base
www.fengrenjicn.com
When returning
sewing machine to
its home position
of machine
and feed guide
.
