(8) Left parallel section
lengthwise compensation .......................35
(9) Needle throwing width of the
right bottom of eyelet setting ..................35
(10) Needle throwing width of the
left bottom of eyelet setting ....................35
(11) Needle throwing width setting ................35
(12) Number of stitches of the
slant taper bar ..........................................35
(13) Number of stitches of the
right side taper bar compensation .........36
(14) Shape of the straight bar .........................36
(15) Number of stitches of the round bar ......37
(16) Left side cut space compensation .........37
(17) Soft start....................................................38
(18) Number of stitches of the
sewing start of thread tension ................38
(19) Number of stitches of the
sewing end of thread tension..................38
(20) Copy destination No. ...............................38
10. HOW TO USE
THE VARIOUS FUNCTIONS .............39
(1) Performing procedure of the
cycle sewing .............................................39
(2) Operating procedure of thread tension
compensation of each section ................40
(3) Changing the setting position of cloth...43
(4) Changing over the
mode of the start switch ..........................43
(5) Changing over the presser movement ...43
(6) Changing over the counter
(DOWN counting) .....................................43
(7) Stop before cloth cut mode .....................43
(8) Setting the pattern data of
cloth cutting knife pressing amount ......44
11. MAINTENANCE .................................45
(1) Height of the needle bar ..........................45
(2) Timing between the
needle and the looper ..............................45
(3) Clearance between the
needle and the looper ..............................47
(4) Adjusting the needle guard .....................47
(5) Installation positions of the
spreaders and the timing to
open/close the spreaders ........................48
中国缝纫机设备网
(6) Position of the presser foot and the
needle entry point ....................................50
(7) Adjusting the knife dropping position ...50
(8) Installing position of the
needle thread trimming knife ..................51
(9) Adjusting the looper thread trimming ....53
(10) Cleaning ....................................................55
(11) Draining .....................................................55
(12) Checking the fan filter..............................55
(13) Replacing the fuse ...................................56
(14) Standard of replacing time
of the gas spring ......................................56
(15) Replacing the gas spring ........................57
12. EXCHANGING GAGUE PARTS
AND OPTIONAL ................................60
(1) Changing the thread trimming method ....60
(2) Exchanging gauge parts .........................61
13. TROUBLES AND CORRECTIVE
MEASURES IN SEWING ...................66
14. MEMORY SWITCH ............................68
(1) Operating procedure ................................68
(2) Memory switch list ...................................68
15. ERROR LIST .....................................70
16. STANDARD PATTERN LIST .............72
xi
