Nivotester FTR525
7.4.1.4
Level limit detection damping
Application
Sensor
→
2000
It is possible, for instance in the case of very turbulent processes, to steady the measuring
signal. To do so, a time can be set over which the measured values are averaged.
Options: 100 ms to 20 s, Off
Setting the damping results in a longer reaction time.
7.4.1.5
Automatic setup of motion detection
Application
Sensor
→
2000
Automatic setup is carried out with movement of bulk solids either present or not
present (in front of the FDR57 transceiver); the option selected for this corresponds to the
state of the bulk flow.
Options: "With movement", "Without movement"
The following manual adjustment functions can be used to carry out fine adjustment of the
microwave barrier or to suit changing application conditions.
7.4.1.6
Manual adjustment lower limit (LL) movement detection
Application
Sensor
→
2000
→ Function 2112
7.4.1.7
Manual adjustment upper limit (UL) movement detection
Application
Sensor
→
2000
→ Function 2113
7.4.1.8
Movement detection damping
Application
Sensor
→
2000
→ Function 2114
Endress+Hauser
Limit detection
→
2100
2110
Motion detection
→
2100
2120
Motion detection
→
2100
2120
Motion detection
→
2100
2120
Motion detection
→
2100
2120
Damping
→
2114
Automatic setup
→
2121
Manual adjustment LL
→
2122
Manual adjustment UL
→
2123
Damping
→
2124
Commissioning
63
