Configuration
 Controller: The multimedia controller
and video programs. A special USB keyboard mode lets you use the controller to
operate the computer connected to the target module:
INPUT DEVICE
Contour ShuttlePRO v2
 LK463 compatible keyboard:
suer modules of the KVM matrix switch. The order of the 108 keys of these keyboards
corresponds to the OpenVMS keyboard layout.
A special USB keyboard mode guarantees that whenever a special key of this key-
board pressed, this action is transmitted to the target computer:
INPUT DEVICE
LK463 compatible keyboard
How to select a USB-HID mode:
1. Press
Ctrl+Num
2. Select the row
3. Select the row
4. Press F2 to save your settings.
1. Click on IP Extenders > [All Extenders]
2. Double-click the computer module of the KVM extender to be configured.
3. Click the General
4. Under USB HID mode
5. Click OK to save your changes.
47 · G&D DP1.2-Vision-IP-Fiber
