Tip: To avoid dripping after removing the juice jug, you may turn the drip-stop to
the closed position (see: 'Properties of Your New Multi Juicer / Drip-Stop Feature').
2. Remove the juice jug from the appliance and push the locking arm out of the
support at the juicer cover. then remove the juicer cover (see: 'Disassembling the
Juicing System').
3. Pull the juicing sieve upwards and out of the juice collector. You will notice a
slight resistance of the drive coupling. Check the juice collector, and juice spout
for obstacles. Additionally check, if the pulp can fall freely into the pulp contai-
ner and will not accumulate at the pulp guttering.
Important: Always brush the base plate of the juicing sieve clockwise to avoid
damage to the knives and for better removing residues of fibres from the knives.
4. Removing residues of food from the juicing sieve:
Rinse the juicing sieve under cold running tap water. You may clean the base
plate of the juicing sieve with the knives by carefully brushing the base plate and
the mesh clockwise with a soft brush and rinse. For checking, if the fine pores
of the mesh are clean, hold the juicing sieve up to the light.
5. Removing obstacles from the juice collector and juice spout:
Place a bowl under the juice spout and open the drip-stop. Then use a small,
fine, and clean brush or a small, soft plastic spatula to push any blocking pulp
down and out. Push any residues of pulp into the pulp container that have been
accumulated at the pulp guttering. Emptying the juice jug and pulp container:
6. To avoid that the lid will fall during pouring, remove the lid of the juice jug,
before slowly pouring the juice. With the pouring shield installed, the froth will
be retained within the juice jug. Grasp the pulp container by the handling groo-
ve and tilt the pulp container a little for pulling it out from under the pulp guttering
of the juice collector. Empty the pulp container over a large bowl.
7. Re-assuming juicing:
Hold the pulp container tilted and push it under the pulp guttering of the juice
collector. May be, you need to lift the juice collector a little. Ensure that the pulp
guttering is reaching over the rim into the pulp container (see: 'Assembling the
Juicing System').
Wipe dry the juicing sieve thoroughly – especially the drive coupling. Replace
the juicing sieve and push it down slightly onto the drive rotor. Then replace the
juicer cover. Lift the locking arm and push the locking arm into the support at the
