Connection
Connection example:

Initial operation

Do not turn the CD tuner on before you have read and understood these operating instructions.
Check again that all connections are correct.

a) Switching the mixing desk on/off

Not observing the the following sequence when switching the mixer on and off could damage
the loudspeakers or the amplifier.
Switching on
• Make sure that all channel faders (11) are set to minimum volume (channel fader pulled right back to the lowest
point).
• Switch on the output devices that are connected to the mixer first.
• Turn the mixing desk on with the POWER switch (26).
• Switch the connected amplifier on. The mixing desk is now ready for operation.
POWER
ON
L
R
MASTER
AC IN
OUTPUT
9V 500mA
AMP
LINE PHONO LINE
L L
R R
LINE 2 PHONO 2 LINE 1
CD
PHONO
PHONO 1
PHONO
33
