Connection and Control Elements
(16) Microphone connection
A dynamic microphone or a condenser microphone with its own power supply and 6.3 mm jack can be
connected to this socket.
(17) TALKOVER selection switch
You use this switch to control the TALKOVER function for the microphone connected to the microphone
connection (16) socket.
Position "OFF":
The DJ microphone is switched to the master output. The level of the other channels is not influenced.
Position ON:
The DJ microphone is switched to the master output. The volume of the other channels is reduced.
TALKOVER position:
The DJ microphone is switched to the master output. The volume of the remaining channels is reduced as
long as the microphone is addressed. If you do not talk into the microphone, the volume of the other channels
is not influenced.
25
24
(18) Ground screws
To prevent buzzing tones, an earth connection can be made through these screw terminals between the
mixer and the earth cables of the record player (mostly black cable with clamp-type socket).
28
26
POWER
ON
L
R
MASTER
AC IN
OUTPUT
9V 500mA
23 22
18
LINE PHONO
L L
R R
LINE 2 PHONO 2 LINE 1
21
LINE PHONO
PHONO 1
20
19
