Connection and Control Elements
(10) CUE LEVEL control
Using this control, you can set the volume of the headphones.
Turn the control knob to the "0" position before plugging in, unplugging or putting on the
headphones or before switching the mixer on or off. Otherwise, there is risk of damage to your
hearing as a result of excessive volume from the headphone output.
(11) Channel fader
The channel faders are for adjusting the level of each channel.
Slide control to the bottom position = minimum channel level
Slide control to the top position = maximum channel level
The channel fader of channels that are not in use should be slid right down. This reduces the possibility
of interference.
(12) Level display
The recording level indicator provides information about the signal of the two channels CH1 and CH2. As far
as possible, the indicator should be kept out of the red area as the music signal may otherwise by distorted.
(13)

Crossfader

With the aid of this slide control, cross-fading takes place between the channels CH1 and CH2.
One channel is faded out on operating the slide control (becomes quieter). At the same time, the other
channel is faded in (becomes louder). With the cross-fader slide control in the centre position, both channels
are reproduced equally.
(14) Pre-listening function via headphones
This function allows you to select the signal to be played back via the headphones.
The changeover switch SPLIT/MIX serves to select the type of playback:
SPLIT: mono playback; channel CH1 is played back on the left earphone, channel CH2 on the right earphone.
MIX: stereo playback; the channels CH1 and CH2 are mixed.
The controller CH1/CH2 (L/R) defines the volume ratio between the left and right headphone on the
headphone output.
(15)

Earphone connection

At this 6.3 mm jack bushing, a commercially available headphone with a 6.3mm jack bush can be connected.
27
