Connection and Control Elements
(19) Switch LINE/PHONO
These switches specifies whether a line device or a record player is connected at the LINE1/PHONO1 or
LINE2/PHONO2 input sockets.
LINE position > a line device (CD player, cassette deck etc.) is connected to the corresponding input
sockets.
PHONO position > a record player (with magnet system) is connected to the corresponding input
sockets.
Always place the switch in the position intended for the device you have connected. Failure to
do so results in distortion, which could damage the mixer and the connected devices.
(20) PHONO connection sockets
You may only connect record players with a magnet system to these sockets.
(21) LINE connection sockets
You may only connect LINE devices to these sockets.
(22) MASTER OUTPUT connection sockets
These asymmetrical stereo cinch outputs are the output sockets for the mixer's output signals. Connect the
amplifier of your system here.
The signal volume is affected by the GAIN controls (5), the channel faders (11) and the MASTER control
(9).
(23) AC IN connection
The low-voltage plug of the enclosed power pack unit is connected here for power supply.
(24/25) connections USB1/2
These sockets serve to connect the USB interface of a computer.
The USB ports are designed as inputs for playback on the computer and output for recording/playing
back the master signal from the mixing desk.
(26) POWER switch
With this switch you turn the mixing desk on or off. In position „I" or ON, the mixing desk is on, in position „0",
the mixing desk is off.
