Connection and Control Elements
(1) MIC LEVEL control
Using this control, you can set the volume of the headphones.
(2/3) Sound control for the microphone input
You can change the tone of the relevant microphone channel using the equaliser controls.
HI controls the treble and LO the bass range.
Turn the control knob as far as it will go to the left for maximum reduction.
Turn the control knob as far as it will go to the right for maximum increase.
Central position = no influence of the signal through the control
(4) Input selection switch
You can use the input selection switches to select between the individual inputs (signal sources) for the
channels.
Example:
If the input selection switch for CH2 is in the position USB 2, this means, that the signal of the device
connected with the port USB 2 is applied to channel CH2. The PHONO2/LINE2 input is not played pack in
this switch position. To play back this input, you have to put the input selection switch to the position PHONO2/
LINE2.
Minimise the volume using the corresponding channel fader before changing over an input
selection switch. Possible differences in volume between the input sources may otherwise
cause sudden excessive volume.
(5) GAIN control unit
Using these rotary controls, you can adapt the mixer inputs to the output level of the source of signal
concerned (record player, CD player etc.) .
(6/7/8) Sound control HI/MID/LO
You can change the sound of the corresponding channel using these equaliser controls.
HI controls the tweeter range MID the midtone range and LO the bass range.
Turn the control knob as far as it will go to the left for maximum reduction.
Turn the control knob as far as it will go to the right for maximum increase.
Central position = no influence of the signal through the control
(9) MASTER control
You can use this control to set the level at the MASTER OUTPUT (22).
